PRECISION ACTIONS

SPECIFICATIONS

• Action Material: 416 Stainless

• Bolt Material: 4340 Carbon Steel

• Coating: DLC

• Lugs/Throw: 6 Lug (2 rings of 3) 70 Degree Throw

• Integral Recoil Lug: Yes

• Integral Rail: Yes - 20 MOA

• Bolt Handle Orientation: Straight

• Mag Compatibility: AICS & AW

• Extractor: M16 Style

• Ejector: Plunger Style

• Bolt Options: .223, .308, Short Magnum Bolt Face Options

• Trigger Compatibility: R700, with Trigger Hanger Options

• Barrel Compatibility: Prefit

• Integrated 20-MOA Picatinny rail

• Integrated recoil lug

• 70-degree bolt lift

• 6-Lug configuration arranged in 2 rings of 3

• Compatible with Remington® 700 short action stocks and chassis systems

• Compatible with Remington® 700 pattern triggers

• Compatible with Faxon Firearms FX7 Prefit barrels & Similar

• Compatible with AICS and AW Magazines

• 416 Stainless Steel Action Body

• 4340 Carbon Steel Bolt - Features Faxon's Original Flame Fluting as a nod to our industry leading barrels

• Polished DLC coating - enhances durability & looks

• Straight interchangeable bolt handle

• M16 Style Extractor

• Plunger Style Ejector

The champion. Zeus is an over-engineered tactical one-piece action designed for special operators, competition shooters, law enforcement, and extreme-range hunters. Finished with a full DLC treatment

• Precision 3-lug receiver with 60° bolt

• Receiver is made of pre-hardened 416 Stainless Steel

• Receiver has an integral .300” recoil lug and 20 MOA Picatinny Rail

• Raceways are electric discharge machined, EDM, for exacting tolerances

• 3 lug, .725” diameter fluted bolt machined from one-piece, pre-hardened 4340 Chrome-Moly

• Receiver and bolt are both DLC treated

• Proprietary Bolt Knob

• Comes standard with quick change barrel feature

• Receiver headspace tolerance and timed threads allow pre fit barrels to be installed by the customer

• Receiver threads are 1.0625”x16 T.P.I.

• Patented threaded trigger pins replace outdated hammered-in style pins

• Accepts Remington style triggers

• Mini M16 extractor

• Improved cantilever style bolt stop provides strength and does not require stock modification

• .062” diameter firing pin

• Roller tipped cocking piece for smooth cocking operation

• Designed to accept AI and AW style magazines

• Remington 700 footprint allows interface with standard stocks and chassis systems

• Zeus is available in short action or long action

• Short action available in .223, .308, .445 ARC/PPC and Mag bolt

• Long action available in .308, Mag, and Lapua bolt

• Weight: 37.76 ounces

The Apollo Lite/Ti is a combination of 416 SS, Titanium, 4340 Chrome-Moly, and 6061 Aircraft-Grade Aluminum.

• Precision 3-lug receiver with 60° bolt

• Receiver is made of pre-hardened 416 Stainless Steel

• Receiver has a dual pinned, 250” titanium recoil lug

• Receiver comes standard with a dual-pinned and 8×32 screwed two-piece 20 MOA Picatinny Rail

• Receiver finished with a full DLC treatment

• Raceways are electric discharge machined, EDM, for exacting tolerances

• 3 lug, .725” diameter fluted bolt machined from one-piece, pre-hardened 4340 Chrome-Moly

• Bolt is DLC treated

• Proprietary Bolt Knob manufactured from solid aluminum

• Receiver headspace tolerance and timed threads allow pre-fit barrels to be installed by the customer

• Receiver threads are 1.0625” x 16 T.P.I.

• Patented threaded trigger pins replace outdated hammered-in style pins

• Accepts Remington style triggers

• Mini M16 extractor

• Improved cantilever style bolt stop provides strength and does not require stock modification

• .062” diameter firing pin

• Roller tipped cocking piece for smooth cocking operation

• Designed for BDL configurations and will accept 3.0″ internal box mags and AI style magazines

• Remington 700 footprint allows interface with standard stocks and chassis systems

• Apollo Lite/Ti is only available in a short action

• Available in .223, .308, .445 ARC/PPC and Mag bolt

• Weight: 26 ounces

The best value backed by superior performance and engineering, when choosing your precision action reciever look no further than Lone Peak Arms.

Available in long and short action Remington 700™ footprint configuration in repeater and single shot versions. Each action is cut from pre-hardened 416R stainless steel (40 rockwell).

RECEIVER

• Receiver raceway cut with wire EDM to precise tolerances

• Magazine well cut for Wyatt extended mag box. Remington standard boxes also compatible

• Wyatt internal overall length--MBE-3 Long Action Box(3.825"), MBE-4 Short Action(2.995")

• Side bolt release

• Bases secured with 8-40 screws and two anti-sheer pins

• Integrated recoil lug(Not Pictured)

• 1.350" diameter

• Long action weight including bolt assembly- 28.5 ounces

• Short action weight including bolt assembly- 26 ounces

• Right or Left hand configurations available

• 1 1/16"x16 tpi barrel thread tenon

• Nitride available on receiver body for additional R1,900

BOLT

One piece fluted bolt constructed from pre-hardened 4340 chrome moly

• Mini M-16 style extractor

• Plunger ejector

• Light weight firing pin assembly provides fastest locktime with .060” diameter firing pin.

• Threaded bolt handle provides ability to interchange bolt knobs

• Nitride surface finish is standard on the bolt.
